Littelfuse DCK silicon carbide Schottky diodes
Littelfuse DCK silicon carbide Schottky diodes offer high-frequency operation and high inrush current capability. These Littelfuse Schottky diodes are available in a 10 A to 40 A rated current range and 650 V or 1200 V voltage ratings. Available in TO-247-2L, TO-220-2L, and TO-247-3L package options, the DCK series is ideal for use in a variety of applications such as solar boosters, AC/DC converters, power factor correction, and more.
characteristic
- TO-247-2L, TO-220-2L, and TO-247-3L packages
- Rated current range from 10 A to 40 A
- Voltage ratings: 650 V and 1200 V
- High-frequency work
- High inrush current capability
apply
- Solar booster
- AC/DC converter
- TV power
- Power factor correction
- Switching power supply
Data sheet
- DCK10I1200HA
- DCK10I1200PA
- DCK10I650HA
- DCK10I650PA
- DCK15I1200HA
- DCK20C1200HB
- DCK20C650HB
- DCK20I1200HA
- DCK20I650HA
- DCK30C1200HB
- DCK30I1200HA
- DCK40C1200HB
- DCK40I1200HA
Pin distribution diagram
